◆ All digital design, high fidelity audio transmission
◆ Build-in local off-line program timing play function, timing programs backup in SD card, automatically timing play
◆ Digital display, can display time or playing process
◆ Can connect to M6402 broadcast control panel, achieve playing main unit programs freely
◆ With USB input, USB audio programs can be timing played
◆ Two network backup design, automatically LAN problem detect and network switch
◆ EMC 24V and short circuit output port
◆ Build-in 2*25W digital amplifier
◆ 1 AUX input, 1 MIC input, 1 AUX output
◆ Local MIC input with mute function
◆4 LED indicate machine working status
◆ 8 push buttons for daily normal operation
-
Technical Parameter
|
Model |
M6401 |
|
AUX Input / Output |
Sensitivity |
1000mV |
|
Frequency response |
20Hz-20KHz |
|
T.H.D |
≤0.1% |
|
S/N |
≥75dB |
|
MIC Input |
Sensitivity |
10mV |
|
Frequency response |
20Hz-20KHz |
|
T.H.D |
≤0.5% |
|
S/N |
≥70dB |
|
MAX output power |
2*25W / 4Ω |
|
1*50W / 8Ω |
|
Control mode |
Manual control, remote control |
|
Line output level |
1V-1.2V |
|
Power supply |
AC 150V-250V/50-60Hz |
|
Dimension (mm) |
(L×W×H) 220×195×50 |
|
Packing dimension (mm) |
(L×W×H) 330×270×125 |
|
Net weight |
1.3kg |
