Description:
◆ 3 MIC inputs, MIC 1 with priority muting function
◆ 2 AUX inputs & 1 output line for additional mixer or amplifier
◆ Individual volume control for each MIC and line input
◆ Bass and treble volume control separately
◆ 5 unit LED level display
◆ Output short-circuit protection and alarm
|
Model: |
PB-200P |
PB-300P |
PB-600P |
PB-1000P |
|
Output Power: |
60W |
120W |
250W |
350W |
|
Output Regulation: |
<3dB from off-load to full load |
|
Speaker Output: |
balanced 4Ω, 100V, 70V |
|
AUX Output: |
600Ω more than 0.775V (0dBm) |
|
Input: |
MIC 1, 2, 3/600Ω, 3.5mV unbalanced |
|
AUX 1, 2/10KΩ, 300mV unbalanced |
|
Frequency Response: |
50Hz-20KHz (±3dB) |
|
Distortion: |
Less than 0.8% at 1KHz, 1/3 rated power |
|
S/N: |
MIC 1, 2, 3: 70dB |
|
AUX 1, 2: 75dB |
|
Tone: |
Bass: ±10dB at 100Hz |
|
Treble: ±10dB at 10KHz |
|
Protection: |
AC fuse; DC voltage; overload; short-circuit |
|
Muting Function: |
MIC 1 overrides other signal inputs with 0~-3dB attenuation |
|
Power Requirements: |
AC220-240V/50-60Hz |
|
Power Consumption: |
120W |
250W |
500W |
650W |
|
Gross Weight: |
12.5Kg |
13.5Kg |
15.5Kg |
16.7Kg |
|
Net Weight: |
10Kg |
11Kg |
13Kg |
14Kg |
|
Dimensions(mm): |
418x88x338 |
